Description
Latch operated by rotating inside lever or key in outside lever Outside lever always fixed
Our new ANSI Grade 2 Commercial Door Levers are 3 Hour UL Listed and feature Adjustable and Removable thru-bolts. Our new lever has thru-bolts that change position to fit existing preps such as Schlage, Best, Yale, Corbin Russwin, Sargent, Arrow and most imports.
Exceed ANSI A 156.2 Series 4000 Grade 2 locked lever torque requirement.
Tested to exceed 400,000 cycles, ANSI Grade 2 requirement
Screw type true through-bolt are provided and recommended for use on high frequency doors
True-bolt prevents lock chassis rotation and disengagement from latch
True through-bolting preventing loosening of the lockset by securely bolting chassis to the door and disengagement from latch.
Wide door range allows quick and easy adjustment for doors ranging from 1-3/8" to 1-3/4" thick
When adjust door thickness, only rotate rose without separate outside lever easily.
Large diameter of mounting plate and rose covers ANSI hollow metal door cutout.
FUNCTION:
Storeroom - Clutching
DOOR THICKNESS:
1 3/8" to 1-3/4"
STRIKE:
4-7/8 x 1-1/4 standard ASA Strike
THRU-BOLTS:
Removable
LATCH BOLT:
1/2"(13MM) throw solid brass, deadlocking on keyed and non-keyed function
BACKSET:
2-3/4"(70MM) standard, optional latch DL238 or SL238
FACEPLATE:
1-1/8" x 2-1/4" Square corner, beveled, for 2-3/4" backset standard
CYLINDER:
"Schlage C" 6-pin keyway, standard with two brass keys per lock.
CERTIFICATIONS:
Exceed ANSI A 156.2 Series 4000 Grade 2 locked lever torque requirement.
Tested to exceed 400,000 cycles, ANSI Grade 2 requirement
BHMA Certified
UL 3-hour Fire Rated Testing
APPLICATIONS:
For offices, schools, hospitals, apartments, hotel/motel and other public buildings.
Specifications
SKU
ADIR28
Manufacturer
ADIR LOCK & DOOR HARDWARE
Categories
ENTRY / EXIT DEVICES
Condition
BRAND NEW
Model
L280C11-KA
